Product no 996482330
Model GSM4212P-100EUS
Brand NETGEAR
EAN 0606449149548
Weight 4.55 kg
Produktbeskrivelse | NETGEAR AV Line M4250-10G2F-PoE+ - switch - 12 porte - Administreret - monterbar på stativ |
Enhedstype | Switch - 12 porte - L3 - Administreret |
Pakningstype | Side til side-luftstrøm monterbar på stativ 1U |
Undertype | Gigabit Ethernet |
Porte | 10 x 10/100/1000 (8 PoE+) + 2 x Gigabit SFP |
Power Over Ethernet (PoE) | PoE+ |
PoE-budget | 125 W |
Præstation | Omkoblingskapacitet: 24 Gbps<br>Firewall-gennemløb (64-byte pakkestørrelse): 17.86 Mpps<br>Latens (1 Gbps): < 2.27 µs |
Kapacitet | VLANs understøttet: 4093<br>ARP-indtastninger: 4000<br>Multicas indgange (IPv4): 512<br>Multicast indgange (IPv6): 128<br>Jumbo-rammestørrelse: op til 12.000<br>IGMP multicast-grupper: 2000<br>MSTP-tilfælde: 16<br>PVST instanser: 32 |
MAC adresse table størrelse | 16K indtastningshukommelse |
Routingprotokol | RIP, IGMPv2, IGMP, PIM-SM, PIM-DM, IGMPv3, PIM-SSM, statisk IPv4 routing, statisk IPv6 routing, MLDv2 |
Protokol til fjernadministration | RMON 1, RMON 2, SNMP, RMON 9, Telnet, HTTPS, SSH, CLI, TACACS+, RADIUS |
Egenskaber | VLAN-understøttet, DoS attack beskyttelse, sFlow, Spanning Tree Protocol (STP) support, DHCP snooping, Quality of Service (QoS), DHCP server, Dynamic ARP Inspection (DAI), DHCP videresendelse, Link Aggregation Control Protocol (LACP), Remote Switch Port Analyzer (RSPAN), Dynamic VLAN Support (GVRP), Multiple VLAN Registration Protocol (MVRP), 16 MB pakkebuffer, IP-kildebekyttelse, Bridge protocol data unit (BPDU), GARP Multicast Registration Protocol (GMRP), Spanning-tree Root Guard (STRG), politikbaseret routing, Authentication, Authorization and Accounting (AAA), LLDP-MED, Private VLAN, Protocol Independent Multicast (PIM), Rapid Reconfiguration of Spanning Tree (RSTP), Link Aggregation Group (LAG) |
Overensstemmelsesstandarder | IEEE 802.3af, IEEE 802.3ad (LACP), IEEE 802.1as, IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.3at, IEEE 802.3az, IEEE 802.1AX, IEEE 802.1Qat, IEEE 802.1Qav |
Effekt | AC 110 V |
Dimensioner (B x D x H) | 44 cm x 20 cm x 4.32 cm |
Vægt | 2.85 kg |
Lokalisering | Europa |
Producentgaranti | ProSAFE livstidsgaranti |
General | |
---|---|
Capacity | VLANs supported: 4093 | ARP entries: 4000 | Multicast entries (IPv4): 512 | Multicast entries (IPv6): 128 | Jumbo frame size: up to 12000 | IGMP multicast groups: 2000 | MSTP instances: 16 | PVST instances: 32 |
Compliant Standards | IEEE 802.3af, IEEE 802.3ad (LACP), IEEE 802.1as, IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.3at, IEEE 802.3az, IEEE 802.1AX, IEEE 802.1Qat, IEEE 802.1Qav |
Device Type | Switch - 12 ports - L3 - managed |
Enclosure Type | Side to side airflow rack-mountable 1U |
Encryption Algorithm | SSL 3.0, TLS 1.2 |
Features | VLAN support, DoS attack prevention, sFlow, Spanning Tree Protocol (STP) support, DHCP snooping, Quality of Service (QoS), DHCP server, Dynamic ARP Inspection (DAI), DHCP relay, Link Aggregation Control Protocol (LACP), Remote Switch Port Analyzer (R |
Flash Memory | 256 MB |
MAC Address Table Size | 16K entries |
Performance | Switching capacity: 24 Gbps | Firewall throughput (64-byte packet size): 17.86 Mpps | Latency (1 Gbps): < 2.27 µs |
PoE Budget | 125 W |
Ports | 10 x 10/100/1000 (8 PoE+) + 2 x Gigabit SFP |
Power Over Ethernet (PoE) | PoE+ |
Processor | X ARM A9: 1.25 GHz |
RAM | 2 GB |
Remote Management Protocol | RMON 1, RMON 2, SNMP, RMON 9, Telnet, HTTPS, SSH, CLI, TACACS+, RADIUS |
Routing Protocol | RIP, IGMPv2, IGMP, PIM-SM, PIM-DM, IGMPv3, PIM-SSM, static IPv4 routing, static IPv6 routing, MLDv2 |
Subtype | Gigabit Ethernet |
Expansion / Connectivity | |
Interfaces | 10 x 10/100/1000 Base-T RJ-45 8 ports (PoE+) | 2 x 1000Base-X SFP | 1 x management (Gigabit LAN) RJ-45 | 1 x console RJ-45 | 1 x USB Type A | 1 x console (USB) Type C |
Power | |
Installed Qty | 1 |
Power Consumption Operational | 17.32 Watt |
Power Consumption Stand by | 8.53 Watt |
Power Device | Internal power supply |
Voltage Required | AC 110 V |
Miscellaneous | |
Cables Included | Console cable | USB-C to USB-A cable |
Compliant Standards | CCC, EN 61000-3-3:2013, EN 55024:2010, YD/T993-1998, IEC60950/EN60950, FCC CFR47 Part 15 B Class A, CNS 13438 Class A, GB 4943.1-2011, EN 55032:2012+AC:2013 Class A, CNS 14336-1, IEEE 1588, ICES-003:2016 issue 6 Class A, CISPR 32:2012, EN 61000-3-2:2 |
Included Accessories | Mounting brackets |
Localization | Europe |
Rack Mounting Kit | Included |
Dimensions & Weight | |
Depth | 20 cm |
Height | 4.32 cm |
Weight | 2.85 kg |
Width | 44 cm |
Manufacturer Warranty | |
Service & Support | Limited warranty - lifetime |
Environmental Parameters | |
Humidity Range Operating | 90% (non-condensing) |
Humidity Range Storage | 95% (non-condensing) |
Max Operating Temperature | 45 °C |
Max Storage Temperature | 70 °C |
Min Operating Temperature | 0 °C |
Min Storage Temperature | -20 °C |
