ARCTIC P14 PWM PST Fan 1-pack Hvid 140 mm
ARCTIC P14 PWM PST - Indsats med blæser - 140 mm - hvid/hvid
-
Product no 997702798
Model ACFAN00197A
Brand
Go to brand's websiteEAN 4895213703116
Weight 0.24 kg
-
Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.
| Produktbeskrivelse | ARCTIC P14 PWM PST - indsats med blæser |
| Produkttype | Indsats med blæser |
| Farve | Hvid/hvid |
| Blæser diameter | 140 mm |
| Blæser-højde | 27 mm |
| Blæser med kugleleje | Strømningsdynamisk leje |
| Omdrejningshastighed | 200 - 1700 rpm |
| Luftstrøm | 72,8 cfm |
| Støjniveau | 0.3 Sone |
| Stik | 4-pins blæser-stikforbindelse, 4-pin blæsersokkel |
| Rated Voltage | 12 V |
| Egenskaber | Puls-bredde modulation (PWM) support, PWM Sharing Technology (PST) |
| Vægt | 194 g |
| Egenskaber | Bokspakke |
| Producentgaranti | 10-års garanti |
| General | |
|---|---|
| Color | White/white |
| Product Type | Case fan |
| Shipping Dimensions (WxDxH) / Weight | 14.3 cm x 2.9 cm x 14.3 cm / 230 g |
| Weight | 194 g |
| Heatsink & Fan | |
| Air Flow | 72.8 cfm |
| Air Pressure | 2.4 mm |
| Cable Length | 40 cm |
| Fan Bearing | Fluid dynamic bearing |
| Fan Diameter | 140 mm |
| Fan Height | 27 mm |
| Features | Pulse-width modulation (PWM) support, PWM Sharing Technology (PST) |
| Noise Level | 0.3 Sone |
| Power Connector | 4-pin fan connector, 4-pin fan socket |
| Power Consumption | 1.44 W |
| Rated Current | 0.12 A |
| Rated Voltage | 12 V |
| Rotation Speed | 200-1700 rpm |
| Start Voltage | 3.9 V |
| Miscellaneous | |
| Features | Box package |
| Manufacturer Warranty | |
| Service & Support | Limited warranty: - 10 years |
| Environmental Parameters | |
| Max Operating Temperature | 40 °C |
| Min Operating Temperature | 0 °C |
